5-Channel Flame Sensor Module

1 Review
Availability: In stock
SKU: 51754

QUICK OVERVIEW

  1. Detecting range: >120 degree
  2. Analog and digital outputs
  3. On-board potentiometer and indicators
  4. 1% resistors to make this module more reliable and precise
  5. Operating Voltage: 3.3V – 9V
  6. Board Diameter: 40 mm.

 450.00

(inc GST)

₹ 381.36 (+18% GST extra)

In stock

Purchase this product now and earn 5 Robu Points!

5-Channel Flame Sensor Module is a 5 channel flame detector module used to detect flame in the larger area( >120 degrees).

If you need a robot which should detect any fire around, then this module will be very useful for you. It detects the fire with 5 flame sensors which are arranged with 30 degrees.

This module outputs an analog signal, which would be more precise, and also digital signal which would be more easy to use, you can adjust the digital output sensitivity by the onboard potentiometer. The 5 LED indicators are helpful in your debugging, the high-precision resistors also make this sensor more precise than other flame sensors.

This module is sensitive to the flame and radiation. It also can detect ordinary light source in the range of a wavelength 760nm-1100 nm. lighter flame test distance of 80cm, for the greater the flame, the farther the distance test.

5-Channel Flame Sensor Module -ROBU.IN


Features :

  1. Analog and digital outputs
  2. On-board potentiometer and indicators
  3. 1% resistors to make this module more reliable and precise
  4. Can output the analog signal can be accurately measured, for high precision applications
  5. Adjustable detection range digital output, analog output sensitivity adjustable design flexibility

Package Includes :

1 x 5-Channel Flame Sensor Module.

Operating Voltage(VDC)

3.3 to 9

Detecting Range(°)

>120

Board Diameter (mm)

40

Total Diameter (mm)

57

Height (mm)

15

Weight (gm)

8

Shipment Weight

0.03 kg

Shipment Dimensions

6 x 6 x 3 cm

15 Days Warranty

This item is covered with a standard warranty of 15 days from the time of delivery against manufacturing defects only. This warranty is given for the benefit of Robu customers from any kind of manufacturing defects.  Reimbursement or replacement will be done against manufacturing defects.


What voids warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
