ARDUINO OPTA RS485 AFX00001

Availability:

In stock


SKU: 1682504
  1. Input: 8x configurable digital / analog (0-10V) input
  2. Processor: STM32H747XI Dual ARM® Cortex®:
    Cortex -M7 core up to 480 MHz
    Cortex -M4 core up to 240 MHz
  3. Connectivity: Support 10/100 Ethernet (TCP/IP or Modbus TCP)
    USB-C

 18,999.00

(Including GST)

In stock

Purchase this product now and earn 190 Robu Points!

Very Low Stock. Order Now !



Have any issues, Get support here.
Have a bulk requirement, mail us to [email protected]
Brand: Arduino
Category: Boards Compatible with Arduino

Arduino Opta is a secure, easy-to-use micro PLC with Industrial IoT capabilities.
Designed in partnership with Finder – leading industrial and building automation device manufacturer – Opta allows professionals to scale up automation projects while leveraging the Arduino ecosystem. Supporting both Arduino sketch and standard PLC languages, including LD (Ladder Logic Diagram) and FBD (Function Block Diagram), it was designed with PLC engineers in mind.

Its powerful STM32H747XI dual-core Cortex®-M7 +M4 MCU allows users to perform real-time control, monitoring and implement predictive maintenance applications.

Secure and durable by design, it supports OTA firmware updates and ensures data security from the hardware to the Cloud thanks to the onboard secure element and X.509 Standard compliance.

Note: For more technical details go through Datasheet in the attachment section

Arduino


Features:

  1. Easy and fast software development, starting from ready-to-use Arduino sketches, tutorials and libraries
  2. Support for standard IEC 61131-3 PLC languages
  3. Fieldbus integration via Modbus TCP (ethernet) and Modbus RTU (serial RS485)
  4. Real-time remote monitoring via intuitive Arduino Cloud dashboards (or third-party services)
  5. Security at the hardware level thanks to onboard secure element and X.509 Standard compliance
  6. Secure OTA firmware updates and Cloud device management
  7. High-power relay switching (4 x 2.3 kW)
  8. Reliable by design, thanks to industrial certifications and Finder’s expertise in switching technology
  9. IP protection: IP20
  10. Certifications: cULus listed, ENEC, CE

Arduino Screenshot 2023 08 09 114542


Package Includes:

1 x ARDUINO OPTA RS485 AFX00001

SKU: 1682504 Category:
Model

ARDUINO OPTA RS485 AFX00001

Input Voltage (V AC)

0-10

Processor

Cortex -M4 core up to 240 MHz, Cortex -M7 core up to 480 MHz, STM32H747XI Dual ARM® Cortex®

Connectivity

Support 10/100 Ethernet (TCP/IP or Modbus TCP) USB-C

RAM (KB/MB):

1MB

Flash Memory (KB/MB):

16MB

Memory

2MB internal

RTC

Typical 10 days power retention at 25°C, NTP sync available through ethernet

output Voltage(V AC)

250

Programming Software:

Arduino programming language via IDE IEC-61131-3: Ladder Diagram (LD) Function Block Diagram (FBD) Sequential Function Chart (SFC) Structured Text (ST) Instruction List (IL), Security: ATECC608B Secure element

Min Supply Voltage(VDC)

12-24

Operating Temperature (°C):

-20 to +50

Shipping Weight 0.1 kg
Shipping Dimensions 10 × 9 × 7 cm
6 Months Warranty

This item is covered with a supplier warranty of 6 months from the time of delivery against manufacturing defects only. This is a quality product from the original manufacturer. Only manufacturing defects are covered under this warranty. Reimbursement or replacement will be done against manufacturing defects.


What voids the warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.

Based on 0 reviews

0.0 overall
0
0
0
0
0

Be the first to review “ARDUINO OPTA RS485 AFX00001”

There are no reviews yet.

Datasheet

Questions and answers of the customers

  1. 0 votes
    Q what is the maximum frequency supported for digital inputs answer now
    Asked by asheesh.aurangabadkar61 on January 15, 2024 11:08 am
    A

    Please go through the datasheet attach in attac... Read more

Only registered users are eligible to enter questions
Country Of Origin: Italy
