Digi Pot 3 Click Board Digital Potentiometer

Availability:

Out of stock

Approx Restocking Date: 25 to 30 Days
SKU: 1574095
  1. Dimensions: 42.9 x 25.4mm
  2. Input Voltage: 3.3V or 5V
  3. Weight:5g

 2,499.00

(Including GST)

Out of stock

Didn’t Find what you are looking for?

You must register to use the waitlist feature. Please login or create an account
Brand: MIKROE
Category: Potentiometer Module

DIGI POT 3 click is a versatile and feature-rich digital potentiometer click with 1024 steps and an internal non-volatile memory (EEMEM), which can be used for storing the wiper position, but also for storing various user data.

The user EEMEM area has 14 words, each with 16-bit length. The Click boardâ„¢ can be used with both unipolar and bipolar signals, selectable by onboard SMD jumpers. The wiper position can be increased or decreased linearly or by the logarithmic scale (6db/step) with a single command. A special scratch register allows direct programming of the wiper position. It can be stored in the non-volatile memory and on the power on, it is automatically restored. This means that the device restores its last position after the power is on – just like its mechanical counterpart.


Features:

  1. Interface: Analog, SPI
  2. Compatibility: mikroBUSâ„¢
  3. Dimensions: 42.9 x 25.4mm
  4. Input Voltage: 3.3V or 5V

Package Includes:

1 x Digi Pot 3 Click Board Digital Potentiometer.

SKU: 1574095 Category:
Type of accessories for development kits

Click board

Gross weight

5 g

Supply voltage

3.3V DC and 5V DC

Click board size

M (42.9 x 25.4 mm)
