ESC Power Distribution Board Soldered XT60 Plug & 3.5mm Banana Bullet Connectors For 250mm Multicopter FPV

(1 customer review)
Availability:

In stock


SKU: 45732
  1. Material: glass fiber
  2. Compatible with MK KK flight control installment pitch of holes
  3. Compatible with MK KK flight control system
  4. Can connect 1-8 ESC.
  5. This has an XT60 plug to connect a battery.
  6. This Distribution board has 8 number of the channel to connect different ESCs with 3.5mm Banana Bullet Connectors.

 399.00

(Including GST)

In stock

Purchase this product now and earn 4 Robu Points!


Have any issues, Get support here.
Have a bulk requirement, mail us to [email protected]
Didn’t Find what you are looking for?

Category: Drone Frame and Accessories
Tags: Multirotors, ESC, Quadcopters, XT60, Power Distribution Board, PDB, Banana

This is ESC Power Distribution Board Soldered XT60 Plug & 3.5mm Banana Bullet Connectors For 250mm Multicopter FPV.  These lightweight distribution boards make powering multi-rotor aircraft easy.

Simply solder a battery connection onto the two central terminals, and you’ve got eight pairs of connections to use – perfect for quadcopters, hexacopters, and even octocopters.

The ESC Power Distribution Board equips Soldered XT60 Plug & 3.5mm Banana Bullet Connectors is great for smaller multirotor builds. They’re compact and lightweight and offer large solder pads – making them easy to work with.

These boards can handle some serious current – up to 20A per output for a quadcopter build or drop that down to 10A each for an octocopter.

We have a module with same board but with a custom connector soldering option, do not forget to check it out

ESC Power Distribution Battery Board


Features :

  1. Material: glass fiber
  2. Compatible with MK KK flight control installment pitch of holes
  3. Compatible with MK KK flight control system
  4. Can connect 1-8 ESC.
  5. This has an XT60 plug to connect a battery.
  6. This Distribution board has 8 number of the channel to connect different ESCs with 3.5mm Banana Bullet Connectors.

Package Includes :

1 x ESC Power Distribution Board Soldered XT60 Plug & 3.5mm Banana Bullet Connectors For 250mm Multicopter FPV

Width (mm):

50

Height (mm):

2

Weight (g):

25

Mounting Holes(mm)

45×35

Shipping Weight 0.03 kg
Shipping Dimensions 6 × 6 × 1 cm
15 Days Warranty

This item is covered with a standard warranty of 15 days from the time of delivery against manufacturing defects only. This warranty is given for the benefit of Robu customers from any kind of manufacturing defects.  Reimbursement or replacement will be done against manufacturing defects.


What voids warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.

Based on 1 review

5.0 overall
1
0
0
0
0

Add a review

  1. [email protected] (verified owner)

    Very useful & handy. Value for money. Quality ok.

    [email protected]

Questions and answers of the customers

  1. 0 votes
    A

    No, because the required voltage range for this... Read more

  2. 1 vote
    Q This is serial connection or parallel ? answer now
    Asked by mohit.mangal2 on August 24, 2020 1:02 pm
    Answered by the admin

    It is a parallel connection. voltage is the sam... Read more

Only registered users are eligible to enter questions
Country Of Origin: China
