M5STACK BALA2 ESP32 Self-balancing Robot Kit


Out of stock

Approx Restocking Date: NA
SKU: 945396
  1. ESP32: 240MHz dual-core, 600 DMIPS, 520KB SRAM, Wi-Fi, dual-mode Bluetooth
  2. Flash Memory: 16MB
  3. LCD: 2.0 inch, 320×240 Color TFT LCD, ILI9342C
  4. Motor Driver: HR8833
  5. Base Controller: STM32F030C8T6
  6. MEMS: BMM150 + MPU6886


(Including GST)

Out of stock

You must register to use the waitlist feature. Please login or create an account
Brand: M5 STACK
Category: Robot Kits and Parts
Tags: BALA2 ESP32, BALA2 ESP32 Self-balancing Robot

BALA2 is short for ‘Balance’, as its name suggests, it is the second generation of the M5Stacks balancing robot series. BALA2 is a Self Balancing Robot consisting of an M5Stack Gray and two wheels(DC motors). The base uses STM32F030C8T6 as the main control and has a two-way encoding motor driver and a built-in 1200mAh battery.

This robotics product comes with preloaded software. A self-balancing robot application that balances the robot vertically using a closed-loop algorithm. You can program it to automatically move around through programming, or you can combine WiFi and Bluetooth to develop remote control functions.

This Robot is controllable by a Smartphone device or a Transmitter. The BALA2 base contains a wealth of interfaces. In addition to the conventional PortB and PortC, it also supports 8-channel servos, of which 4 channels can be directly connected, and the remaining 4 channels need to be connected from the inside of the base. Even if you have never attempted such a balancing robot program, you can quickly get the hang of it and control it through UIFlow. The self-balancing robot uses data from the Accelerometer and Gyroscope to correct its orientation and position. The 2 DC driver module communicates with M5Stack Gray through I2C(0x3A).


To get complete code, please click, click


  1. 9-DOF IMU
  2. Two-wheel drive, PID control balance
  3. Grove extension ports
  4. 8-channel servo drive, 4-channel external connection, 4-channel built-in
  5. Support WiFi/Bluetooth, programmable
  6. Built-in speaker
  7. TF Card Support
  8. LEGO™ Compatible
  9. Programming Support
    1. Python
    2. UIFlow (Blockly)
    3. Arduino

Package Includes:

  1. 1x M5Stack Gray + BALA2
  2. 4x Wheel connector
  3. 2x HY2.0-4P Cables(20cm)
  4. 2x Bricks
  5. 1x Hex wrench
  6. Type-C USB Cable(120cm)

240MHz dual-core




BMM150 + MPU6886

Motor Driver


Base Controller


Length (mm)


Width (mm)


Height (mm)


Weight (gm)


Shipment Weight

0.04 kg

Shipment Dimensions

10 × 10 × 9 cm
