NEMA17 PR42HS48-1204A-20F 5.6kg-cm Stepper Motor-D Type Shaft

Availability:

In stock


SKU: 1736854
  1. Model: PR42HS48-1204A-20F
  2. Step Angle: 1.8 °
  3. Holding Torque: 5.6 kg-cm
  4. Shaft Type: D Type

 939.00

(Including GST)

In stock

Purchase this product now and earn 10 Robu Points!

Free Delivery above ₹499
Free Delivery
above ₹499
1 Year Warranty
15 Days Warranty
Cash On delivery
Cash on Delivery*

Didn’t find what you are looking for?

Brand: Generic
Category: Nema 17 Stepper Motors, 3D Printer Stepper Motors

The stepper motors move in precisely repeatable steps, hence they are the motors of choice for the machines requiring precise position control. The NEMA17 5.6 kg-cm Stepper Motor can provide 5.6 kg-cm of torque at 1.2A current per phase. The motor’s position can be commanded to move or hold at one position with the help of Stepper Motor Drivers. The NEMA17 5.6 kg-cm Stepper Motor provides excellent response to starting, stopping, and reversing pulses from the stepper motor driver.

They are very useful in various applications, especially those that demand low speed with high precision. Many machines such as 3D Printers, CNC Router and Mills, Camera Platforms, XYZ Plotters etc.

It is a brushless DC motor, so the life of this motor is dependent upon the life of the bearings. The position control is achieved by a simple Open Loop control mechanism so doesn’t require complex electronic control circuitry.

It comes with a detachable 72cm cable which makes wiring and rewiring very fast and easy to work. The design of this cable is such that it can directly be mounted on a stepper motor controller. So, playing with the connection is done with just a snap of the fingers. The motor’s shaft has been machined for good grip with a pulley, drive gear, etc., and especially avoiding stall or slip.

Note :

  1. The Nema17 5.6kgcm Stepper motor dimensions and weight may have  ±2% error.
  2. Resonances can occur because of improper installment.
  3.  Not easy to operate at extremely high speeds.
  4. The cable comes with a Motor that has a connector from one end to connect it to the motor while another end of the cable is open for soldering

Features :

  1. The input pulse decides the rotation angle of the motor.
  2. High accuracy of around 3 to 5% a step.
  3. Provides good starting, stopping, and reversing.
  4. Control of this motor is less costly because of the exclusion of complex control circuitry.
  5. The speed is proportional to the frequency of the input pulses.

Package Includes :

1 x NEMA17 PR42HS48-1204A-20F 5.6kg-cm Stepper Motor-D Type Shaft

Item Type:

NEMA 17 Stepper Motor

Shaft Type

D type

Step Angle (Degree)

1.8

Model No.

PR42HS48-1204A-20F

Rated Current (A)

1.2 A

Lead Wires

4

Holding Torque (kg-cm)

5.6

Detent Torque (kg-cm)

0.28

Shaft Diameter (mm)

5

Shaft Length (mm)

22

Motor Length (mm)

47

Frame Size (mm)

42 x 42

Shipping Weight 0.367 kg
Shipping Dimensions 10 × 10 × 6 cm
