Orange OS90 6V 1.5kg.cm Analog Brush Servo Motor

Availability:

Out of stock

Approx Restocking Date: 15th July, 2024
SKU: 867242
  1. Input Voltage Range (VDC):  4.8V-6V
  2. Rated Torque: 0.5kg.cm@6V
  3. Gears Type: Plastic Gear
  4. Connector: JR
  5. Size (L x W x H) mm: 22.5 x 12 x 22.5

 299.00 (Incl. GST)

Out of stock


Free Delivery above ₹499
Free Delivery
above ₹499
1 Year Warranty
1 Month Warranty
Cash On delivery
Cash on Delivery*

Didn’t find what you are looking for?

You must register to use the waitlist feature. Please login or create an account
Brand: Orange
Category: Orange RC Servo Motors
Tags: OS90

We are importing and selling a diverse range of servo motors from various manufacturers for a long time and with tolerable feedback on it, we have come to know the issues faced by our customers regarding quality and efficiency. Owing to the responses of them we compelled to find the servo motor having good quality not only from outside but also from inner gear construction. So here we are launching our Own Orange Premium Quality servo motor series with Metal gears construction where we can assure you that you will receive the best quality of motor that you are paying for with a 1-month of robu warranty.

We got constructed and tested this Orange Premium Servo with Steel gear material inside gears and a tight sturdy plastic case which makes them water and dust resistant which is a very must feature required in Boats, and RC Monster Trucks, etc. It equips a 3-wire JR servo plug which is compatible with Futaba connectors too.

The Heavy Duty Orange OS90 6V 1.5kg.cm 120° Analog Brush Servo Motor with any servo code, library, and hardware. It rotates approximately 120-degree, 60 degrees in each direction. This motor package comes with a selection of hardware and arms.

Wire Description:

  • RED – Positive
  • Brown – Negative
  • Orange – Signal
Explore the range of Orange Premium Servo Motors in the category. Click Here

Features:

  1. The connection cable is thicker
  2. Equips high-quality motor
  3. High resolution
  4. Fast control response
  5. Constant torque throughout the servo travel range
  6.  Excellent holding power
Please go through Datasheet in attachments for more technical details and Dimensional Drawing

Package Includes:

1 x Orange OS90 6V 1.5kg.cm Analog Brush Servo Motor

1 x Set of Horns

1 x Set of Screws

SKU: 867242 Category: Tag:
Model

OS90

Operating Voltage (VDC):

4.8 ~ 6

No load Speed (RPM)

0.10sec/60º@6V, 0.12sec/60º@4.8V

Stall Torque(Kg-Cm)

[email protected], 1.5kg.cm@6V

Operating Temperature (°C)

-15℃~70℃

Dead Band Width ( μs)

8

Gear Material

Plastic

Rotational Degree

180º

Cable Length (cm)

25

Command Signal

PWM

Connector

JR

Length (mm):

22.5

Width (mm):

12

Height (mm):

22.5

Weight (g):

9

Shipping Weight 0.01 kg
Shipping Dimensions 3 × 2 × 2 cm
1 Month Warranty

This item is covered with a standard warranty of 1 month from the time of delivery against manufacturing defects only. This warranty is given for the benefit of Robu customers from any kind of manufacturing defects. Replacement will be done against manufacturing defects.


What voids warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.

DATASHEET

Questions and answers of the customers

There are no questions yet. Be the first to ask a question about this product.

Only registered users are eligible to enter questions
Country Of Origin: China
