PT1000-S Waterproof 1m 30mm Stainless Steel Pole Probe Temperature Sensor

Availability:

Out of stock

Approx Restocking Date: 10th April, 2024
SKU: 43887
  1. Model number: FTARP05 series.
  2. Mounting form Polish rod probe
  3. The Probe material: Stainless steel.
  4. Probe diameter: 4mm.
  5. Length of the probe: 30mm.
  6. Cabel material Silver plated copper (not insulated), PTFE Silver plated copper (Waterproof, insulated).
  7. Accuracy ±(0.3°C+0.5%|t|).
  8. Thermal response time: <0.5 sec.

 167.00

(Including GST)

Out of stock

Didn’t Find what you are looking for?

You must register to use the waitlist feature. Please login or create an account
Category: Temperature & Humidity Sensor
Tags: Temperature Sensor, Waterproof Temperature Sensor, PT100-S, PT100S, PTFE FTARP05, FTARP05

For precision temperature sensing, nothing beats a PT1000-S Waterproof 1m 30mm Stainless Steel Pole Probe Temperature Sensor. Resistance temperature detectors (RTDs) are temperature sensors that contain a resistor that changes resistance value as its temperature changes, basically a kind of thermistor.

In this sensor, the resistor is actually a small strip of Platinum with a resistance of 1000 ohms at 0°C, thus the name PT1000. Compared to most NTC/PTC thermistors, the PT type of RTD is much most stable and precise (but also more expensive). PT1000’s is useful to measure temperature in laboratory and industrial processes; and have developed a reputation for accuracy (better than thermocouples), repeatability, and stability.

This high-temperature PT1000 sensor is equipped with a 316L stainless steel shield (try saying that five times fast!) that is good for up to 550°C.

How does the sensor work?

  1. As the temperature in your application changes then the electrical resistance will also change. An increase in temperature will increase the resistance of the temperature sensor.
  2. The measurement is completed by your instrument by applying a small measurement voltage and utilizing a bridge type circuit.

Pt1000 1M 30M Temp Sensor


PT1000 features:

  1. Based on resistance measurement principles.
  2. Resistor material is Platinum with a value of 1000 ohm at temperature 0°C.
  3. Platinum has a positive resistance-temperature factor; resistance increases with rising temperature.
  4. Resistance variation is a function of temperature: 3.85Ω/°C nominal.
  5. High accuracy and stability compared to thermocouples, silicon-based temperature sensors, or thermistors.

Package Includes :

1 x PT1000-S Waterproof 1m 30mm Stainless Steel Pole Probe Temperature Sensor.

Temperature Range(°C)

-200 to 420

Probe Material

Stainless Steel

Probe Diameter(mm)

4

Probe Length(mm)

30

Accuracy

±(0.3°C+0.5%|t|)

Response Time(s)

<0.5

Cable Length (m):

1

Shipping Weight 0.01 kg
Shipping Dimensions 8 × 6 × 2 cm
15 Days Warranty

This item is covered with a standard warranty of 15 days from the time of delivery against manufacturing defects only. This warranty is given for the benefit of Robu customers from any kind of manufacturing defects.  Reimbursement or replacement will be done against manufacturing defects.


What voids warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
