Sunon 8025 12VDC 1.66W Cooling Fan

Availability:

In stock


SKU: 870206
  1. Operating Voltage: 12VDC
  2. Power Consumption: 1.44W
  3. Body and Blade Constructed from Thermoplastic PBT of UL 94V-0
  4. Single Phase 4 Pole Brushless DC Motor
  5. Lubricated Sleeve Bearing System.
  6. Counterclockwise Rotation Direction if Viewed from front of Fan Blade

 149.00

(inc GST)

₹ 126.27 (+18% GST extra)

In stock

Prices shown above are Inclusive of GST

Purchase this product now and earn 2 Robu Points!
Brand: Sunon
Category: Cooling Fans

This is a High-Quality 80  x 25 mm size Cooling Fan from Sunon. The cooling fan consists of a 4-pole Brushless DC Motor with a precise lubricated sleeve bearing system, this cooling fan can deliver an airflow up to 41 CFM, which is sufficient enough to keep the electronics cool.

Find more details about the product in the attachment section


Features:

  1. High-Quality Fan with Good Air Flow
  2. Body and Fan Blade Made from Thermoplastic PBT of UL 94V-0
  3. Precise Vapo Bearing System
  4. Single Phase 4 Pole Brushless DC Motor
  5. Easy to use

Package Includes:

1 x Sunon 8025 12VDC 1.66W Cooling Fan

Model

EF80251S1-1000U-A99

Rated Speed (RPM)

3200

Operating Voltage (VDC)

12

Operating Current (A)

0.138

Noise Level (dB)

33

Operating Temperature (°C)

-10 to 70

Power Consumption (Watt)

1.66

Insulation Class

UL Class A

Length (mm)

80

Width (mm)

25

Height (mm)

80

Weight (gm)

75

Cable Length (cm)

30

Shipment Weight

0.078 kg

Shipment Dimensions

9 × 9 × 1 cm

15 Days Warranty

This item is covered with a standard warranty of 15 days from the time of delivery against manufacturing defects only. This warranty is given for the benefit of Robu customers from any kind of manufacturing defects.  Reimbursement or replacement will be done against manufacturing defects.


What voids warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
