Ublox NEO-M8N GPS Module with Compass for APM and PIXHAWK FC (Default Connector: PIX)
Ublox NEO-M8N GPS Module with Compass for APM and PIXHAWK FC (Default Connector: PIX) Ublox NEO-M8N GPS Module with Compass for APM and PIXHAWK FC (Default Connector: PIX) Ublox NEO-M8N GPS Module with Compass for APM and PIXHAWK FC (Default Connector: PIX) Ublox NEO-M8N High Precision GPS Module with Built in Compass for PIXHAWK and APM FC

Ublox NEO-M8N GPS with Compass for APM and PIXHAWK FC (Default Connector: PIX)

5 Review(s)
Availability: In stock
SKU: 57286

QUICK OVERVIEW



  1. Ready to Connect to PIXHAWK FC with 6-pin connector Attached
  2.  Receiver type 72-channel Ublox M8 engine
  3.  Galileo-ready E1B/C (NEO-M8N)
  4.  Nav. update rate1 Single GNSS: up to 18 HZ
  5.  Acquisition Cold starts: 26 s
  6. Onboard Compass



 1,890.00 (inc GST)

In stock

Purchase this product now and earn 19 Robu Points!
Category:
Brands:Ublox

This is new generation Ublox NEO-M8N High Precision GPS Module with Built-in Compass for PIXHAWK and APM FC (Ready to connect to PIXHAWK FC) with onboard Compass, low power consumption, and high precision, the ultimate accuracy is 0.6 meters, actually almost 0.9 meters, greater than the previous generation NEO-7N 1.4-1.6 meters accuracy, support GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1 protocol, and mode or more.

Additionally, you can connect the same module to APM Flight Controller just after swapping the extra 5-pin connector provided in Package.

So if you want GPS telemetry for your FPV flying or camera ship?  This new generation Ublox GPS NEO-M8N is the answer.  Capable of accuracy between 0.6 and 0.9 meters it is a significant improvement over previous models. Sattelite searching and acquisition is very fast, generally taking around ten seconds to locate and acquire up to 6 satellites.  It also has a built-in compass with a 10Ghz refresh rate and a low noise figure which ensures this GPS module offers excellent performance.

The NEO-M8N provides the best performance and easiest RF integration of all the NEO-M8 configurations. The NEO form factor allows easy migration from previous NEO generations. Sophisticated RF-architecture and interference suppression ensure maximum performance even in GNSS-hostile environments. NEO-M8 combines a high level of robustness and integration capability with flexible connectivity options. The future-proof NEO-M8N includes an internal Flash that allows simple firmware upgrades for supporting additional GNSS systems.

Ublox NEO-M8N GPS Module for APM APM2.52 APM Flight Controller with Case and GPS Antenna Mount to protect the GPS preventing electromagnetic interference. A new generation Ublox GPS NEO-M8N GPS Module, with low power consumption and high precision, the ultimate accuracy is 0.6 meters, actually almost 0.9 meters, greater than the previous generation NEO-7N 1.4-1.6 meters accuracy. Support GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1 protocol, and mode or more. The NEO-M8N and ceramic antenna make this a very accurate receiver, fast locks & lots of satellites, and the stand is very sturdy to protect the GPS preventing electromagnetic interference.

Note: When using 2.8 boards with our GPS module must remove the jumper, if you need to calibrate, make the control and GPS compass direction same and keep the two position fixed(cannot make any move, must fix them on the quadcopter and then calibrate, or it will be failed.)


Connector difference of PIXHAWK and APM FC:

Ublox NEO-M8N

Note: This Module comes with 6 pin connector connected by default (i.e.Ready to connect to PIXHAWK FC) and extra 5 pin connector for APM FC for Swapping.

If you need the module with 5 pins connector connected by default (i.e.Ready to connect to APM FC), It is  also available on our site having  SKU: 28952   (Click to see the product)

Watch the video to know how to swap the connectors.


Features:

  1.  GPS/QZSS L1 C/A, GLONASS L10F, BeiDou B1
  2.  SBAS L1 C/A: WAAS, EGNOS, MSAS
  3.  Galileo-ready E1B/C (NEO-M8N)
  4. Onboard Compass
  5.  Assistance AssistNow GNSS Online
  6.  AssistNow GNSS Offline (up to 35 days)
  7.  AssistNow Autonomous (up to 6 days)
  8.  OMA SUPL & 3GPP compliant
  9.  Oscillator TCXO (NEO-M8N/Q),
  10.  Crystal (NEO-M8M)
  11.  RTC crystal Built-In
  12.  Noise figure On-chip LNA (NEO-M8M). Extra LNA for
  13.  lowest noise figure (NEO-M8N/Q)
  14.  Anti-jamming Active CW detection and removal. Extra
  15.  onboard SAW bandpass filter (NEO-M8N/Q)
  16.  Memory ROM (NEO-M8M/Q) or Flash (NEO-M8N)
  17.  Supported antennas Active and passive
  18.  Odometer Travelled distance
  19.  Data-logger For position, velocity, and time (NEO-M8N)

Package Includes:

1 x Ublox NEO M8N GPS for Pixhawk and APM flight controller
1 x Extra 5-pin Connector  for APM FC

Model

Ublox NEO-M8N

Receiver Type

72-channel Ublox M8 engine.

Main Chip

Ublox NEO-M8N

Supply Voltage (V)

0.5~3.6

Sensitivity

Tracking & Navigation: -161 dBm

Position Accuracy

Autonomous: 2.5 m
SBAS: 2.0 m

Acceleration

<4g

Navigation Update Rate

up to 18 HZ.

Operating Temperature Range

-45ºc to 105°c

Tracking Sensitivity

-161 dBm

Co-Ordinate System

WGS-84

Capture Time

0.1s Average

Cold Start Time

30s

Warm Start Time

1s

Boot Time

1s Average

Maximum Altitude

18000

Dimensions (mm) LxWxH

54 x 22 (Dia x W)

Weight (gm)

23g

Cable Length

20 cm

Shipment Weight

0.06 kg

Shipment Dimensions

10 x 8 x 6 cm

5 reviews for Ublox NEO-M8N GPS with Compass for APM and PIXHAWK FC (Default Connector: PIX)

  1. Rated 5 out of 5

    Vishal Mehra (verified owner)

    Original M8N!

  2. Rated 5 out of 5

    jyotirmoypatra1@gmail.com (verified owner)

    good gps.original m8n gps.I get 7 satellite in my room.

  3. Rated 5 out of 5

    Simon George (verified owner)

    Good gps. Comes with 3.3v regulator. You can give 5v direct.
    Pull up resistors were needed on mag sda and scl lines to clear i2c errorrsm.
    Working great with omnibus f4 pro v2 and inav

  4. Rated 5 out of 5

    abidikar@gmail.com (verified owner)

    It is one the best GPS module. Compatible with APM & PIXHAWK flight controllers.

  5. Rated 5 out of 5

    SUJEET KUMAR YADAV

    Very good GPS module for APM / pixhawk. Using it from 1 year. Locks satellites within 30seconds.
