Waveshare Environment Sensor HAT for Raspberry Pi, I2C Bus

Availability:

In stock


SKU: 1219062
  1. 40PIN GPIO, Compatible with all the Raspberry Pi Boards.
  2. Onboard TSL25911FN digital ambient light sensor, for measuring IR and visible light
  3. Onboard BME280 sensor, for measuring temperature, humidity, and air pressure
  4. Onboard ICM20948 motion sensor, accelerometer, gyroscope, and magnetometer
  5. Onboard LTR390-UV-1 sensor, for measuring UV rays
  6. Onboard SGP40 sensor, for detecting ambient VOC

 4,039.00

(inc GST)

In stock

Select below products to add together

Micro USB Cable for Raspberry Pi ₹ 53

New Price: ₹ 4039


  • If order is more than Rs.499, shipping charges are free for Standard Shipping and Speed Post.
  • Same Day Delivery available on order before 01:00 PM(except Sundays, Public holidays).
  • Same Day Delivery not available if cart weight is more than 2kg.

  • Purchase this product now and earn 41 Robu Points!


    For bulk and B2B enquiries kindly mail us at [email protected]
    Brand: WAVESHARE
    Category: Environmental Sensors

    This environment sensors module gives Raspberry Pi the ability to collect environment data like temperature & humidity, air pressure, ambient light intensity, VOC, IR ray, UV ray, etc. It can also be used to build a robot that can detect motion and orientation


    Whats on Board:

    1. Raspherry Pi 40PIN
      1. For connecting to Raspberry Pi easily
    2. TSL25911FN
      1. Digital ambient light sensor, for measuring IR and visible light
    3. LTR390-UV-1
      1. UV sensor
    4. SGP40
      1. VOC sensor
    5. ICM20948
      1. 3-axis accelerometer, 3-axis gyroscope, 3-axis magnetometer
    6. BME280
      1. Measuring temperature, humidity, and air pressure sensor
    7. Voltage level translator
      1. 5V to 1.8V
    8. Regular
      1. 5V to 3.3V/1.8V

    Features:

    1. 40PIN GPIO, Compatible with all the Raspberry Pi Boards.
    2. Onboard TSL25911FN digital ambient light sensor, for measuring IR and visible light
    3. Onboard BME280 sensor, for measuring temperature, humidity, and air pressure
    4. Onboard ICM20948 motion sensor, accelerometer, gyroscope, and magnetometer
    5. Onboard LTR390-UV-1 sensor, for measuring UV rays
    6. Onboard SGP40 sensor, for detecting ambient VOC
    7. Onboard 1.3inch OLED display, for displaying environment data in real-time
    8. I2C bus allows reading and displaying data by just using two wires
    9. Comes with development resources and user manual (python examples)

    Package Includes:

    1 x Environment Sensor HAT
    1 x 2x20PIN female header
    1 x 4PIN header
    1 x RPi screws pack (2pcs)

    SKU: 1219062 Category:
    TSL25911FN DIGITAL AMBIENT LIGHT SENSOR

    I2C address: 0x29
    Effective: range0~88000Lux

    BME280 TEMPERATURE, HUMIDITY, AND AIR PRESSURE SENSOR

    I2C address: 0x76
    Temperature detection: -40 ~ 85℃ (0.01℃ resolution, ±1℃ accuracy)
    Humidity detection: 0~100%RH (0.008%RH resolution, ±3%RH accuracy, 1s response time, ≤2%RH delay)
    Air pressure detection: 300~1100hPa (0.18Pa resolution, ±1hPa accuracy)

    ICM20948 MOTION SENSOR (9-DOF: 3-AXIS ACCELEROMETER, 3-AXIS GYROSCROPE, 3-AXIS MAGNETOMETER)

    I2C address: 0x68
    Accelerometer resolution: 16-bit
    Accelerometer range (configurable): ±2, ±4, ±8, ±16g
    Gyroscope resolution: 16-bit
    Gyroscope range (configurable): ±250, ±500, ±1000, ±2000°/sec
    Magnetometer range: ±4900µT
    Magnetometer resolution: 16-bit

    LTR390-UV-1 UV SENSOR

    I2C address: 0x53
    Response wavelength: 280nm – 430nm

    SGP40 VOC SENSOR

    I2C address: 0x59
    Measuring range: 0 ~ 1,000 ppm ethanol equivalent
    Limit condition: < 0.05 ppm ethanol equivalent OR < 10 % preset concentration point (the larger one should prevail)
    Response time: < 10 s (tau 63 %)
    Start time: < 60 s

    Shipment Weight

    0.017 kg

    Shipment Dimensions

    7 × 6 × 1 cm

    6 Months Warranty

    This item is covered with a supplier warranty of 6 months from the time of delivery against manufacturing defects only. This is a quality product from the original manufacturer. Only manufacturing defects are covered under this warranty. Reimbursement or replacement will be done against manufacturing defects.


    What voids the warranty:

    If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
