USR-TCP232-302 IOT RS232 to Ethernet Converter (without power adapter)

Availability:

Out of stock
SKU: R164237
Add to Wishlist
  1. Model: USR-TCP232-302
  2. Type: RS232 to Ethernet Converter
  3. Power: DC 5.0V to 36.0V
  4. Network: 10/100 Mbps Ethernet (RJ45)
  5. Serial Ports: RS232
  6. Protocols: TCP/UDP, Modbus, ARP

For bulk orders or B2B inquiries, email us: [email protected]

₹ 2,097.00 (Incl. GST)

Out of stock

Bulk Order
Have a Bulk Order?
Click Here
Need Support
Need Support?
Click Here
Free Delivery above ₹999
Free Delivery
above ₹999
1 Year Warranty
6 Months Warranty
Cash On delivery
Cash on Delivery*
Didn’t find what you are looking for?

You must register to use the waitlist feature. Please login or create an account
Brand: PUSR
Category: USB Interface Module

The USR-TCP232-302 is a high-performance RS232 to Ethernet converter designed for industrial and IoT applications. It enables seamless communication between serial devices and Ethernet networks, allowing legacy equipment to integrate easily into modern network infrastructures. The converter supports multiple serial interfaces RS232 and provides a reliable solution for remote monitoring, automation, and industrial control systems.

Features of rs485 ethernet converter: small size, installed easily.

Features:

  1. Multi-Serial Interface: Supports RS232.
  2. Ethernet Connectivity: 10/100 Mbps Ethernet (RJ45).
  3. Power Input: DC 5.0V to 36.0V, with DC 5.5×2.1mm connector.
  4. Current Consumption: 150mA @ 5V.
  5. Status Indicators: PWR, WORK, LINK, TX, RX for real-time monitoring.
  6. Transmission Modes: TCP server, TCP client, UDP server, UDP client.
  7. Protocol Support: TCP/UDP, Modbus, ARP, ICMP.
  8. Temperature Range: Operates from -40°C to +85°C.
  9. Configuration: Configurable via web interface, software, or AT commands.
  10. Certifications: CE, FCC, ROHS certified for quality and safety.

Package Includes:

1 x USR-TCP232-302 IOT RS232 to Ethernet Converter (without power adapter)

SKU: R164237 Category:
Model Name

USR-TCP232-302
Processor

ARM Cortex M0
Power Supply (V)

DC 5 to 36
Serial Port

1 x RS232
Operating Temperature (°C):

-40 to 85
Dimensions (mm) :

71 x 60 x 25
Weight (g):

114
Network Protocol

TCP,UDP,IPV4,ARP,ICMP,DHCP,NTP,HTTP,TLS/SSL V3,DNS,IGMP,SNMPV1/V2C,MQTT
Wireless Network Mode

TCP Server/ TCP client/ UDP Server/UDP Client/ httpsD Client
Input current (mA)

150 @5V
Shipping Weight 0.16 kg
Shipping Dimensions 16 × 11 × 6 cm
6 Months Warranty

This item is covered with a supplier warranty of 6 months from the time of delivery against manufacturing defects only. This is a quality product from the original manufacturer. Only manufacturing defects are covered under this warranty. Replacement will be done against manufacturing defects.

What voids the warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.

Based on 0 reviews

0.0 overall
0
0
0
0
0

Be the first to review “USR-TCP232-302 IOT RS232 to Ethernet Converter (without power adapter)”

There are no reviews yet.

Datasheet

DOWNLOAD

Questions and answers of the customers

There are no questions yet. Be the first to ask a question about this product.

Only registered users are eligible to enter questions
Country Of Origin: China
