SeeedStudio Grove Buzzer

Availability:

In stock


SKU: 592166
  1. Operating voltage: 3.3 V/5V
  2. Output sound: ≥85 dB
  3. Resonant frequency: 2300±300 Hz
  4. Multipurpose piezoelectric buzzer
  5. Easy to use for beginners

 199.00

(Including GST)

In stock

Select below products to add together

SeeedStudio Grove 4 pin Male Jumper to Grove 4 pin Conversion Cable 20cm(Pack of 5) ₹ 149
SeeedStudio Grove Universal 4 pin 20cm Unbuckled Cable (Pack of 5) ₹ 179

New Price: ₹ 199


Purchase this product now and earn 2 Robu Points!

Very Low Stock. Order Now !



Have any issues, Get support here.
Have a bulk requirement, mail us to [email protected]
Didn’t Find what you are looking for?

Category: Piezo Buzzer Module
Tags: Buzzer, grove buzzer, grove piezo

This Grove – Buzzer v1.2 module has a piezo buzzer as its main component. The piezo element makes a clicking sound each time when it is pulsed with current. If we pulse it at the right frequency (for example, 440 times per second to make the note middle A), these frequent clicks will run together to produce a little melody.

You can use this Grove – Buzzer as an audio element, a sound notification, an alarm, or even a little tune! You can use it for various purposes. This buzzer is a great way to indicate something is happening with your GrovePi or GoPiGo robot car! Connect this buzzer to digital outputs, and you’ll hear a tone when the output gets high. Alternatively, you can connect it to an analog pulse-width modulation output to generate various tones and effects.

For all Grove users (especially beginners), Seeed Studio provides guidance PDF documents. Please download and read through Preface – Getting Started and Introduction to Grove before your using the product. This is a suitable product for not only Grove users but also all electronics enthusiasts. So, why wait? Buy now!


Features:

  1. Easy to use
  2. Multipurpose piezoelectric buzzer
  3. Uses Standard 4-pin Grove Cables to connect to other Grove modules such as Grove Power Modules and Grove – Base Shield

Useful links:

Tutorial


Project Links:
  1. NFC Card Controlled Remote Car
  2. Water Sensor Project
  3. Automatic sunshade for the home
  4. The Bus Horn
  5. Grove – Introduction in a Buzzer
  6. Water Waste Monitor

Package Includes:

1 x Grove – Buzzer v1.3

SKU: 592166 Category: Tags: , ,
Operating Voltage (VDC)

3.3 ~ 5

Resonant Frequency

2300?300 Hz

Sound Output

?85 dB

Length (mm):

25

Height (mm):

10

Width (mm):

20

Mounting hole diameter (mm)

2

Weight (g):

4

Shipping Weight 0.005 kg
Shipping Dimensions 7 × 4.5 × 1 cm
6 Months Warranty

This item is covered with a supplier warranty of 6 months from the time of delivery against manufacturing defects only. This is a quality product from the original manufacturer. Only manufacturing defects are covered under this warranty. Reimbursement or replacement will be done against manufacturing defects.


What voids the warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.

Based on 0 reviews

0.0 overall
0
0
0
0
0

Be the first to review “SeeedStudio Grove Buzzer”

There are no reviews yet.

User Manual

CDC File

Grove - Buzzer V1.0 Eagle Schematic File

Grove - Buzzer V1.1 Eagle Schematic File

S9013 Datasheet

Questions and answers of the customers

There are no questions yet. Be the first to ask a question about this product.

Only registered users are eligible to enter questions
Country Of Origin: China
