MPU-6050 3-Axis Accelerometer and Gyro Sensor

(22 customer reviews)
Availability:

In stock


SKU: 2846
  1. Chip built-in 16bit AD converter, 16-bit data output
  2. Driver Chip: MPU6050
  3. Operating Voltage: 3-5V DC
  4. Communication: I2C/IIC Protocol
  5. Gyro Range: ± 250, 500, 1000, 2000 °/s
  6. Accelerometer Range: ± 2 ± 4 ± 8 ± 16 g

 113.00

(Including GST)

In stock

Select below products to add together

Male to Female Jumper Wires 40 Pin 30cm ₹ 63

New Price: ₹ 113


Purchase this product now and earn 2 Robu Points!


Have any issues, Get support here.
Have a bulk requirement, mail us to [email protected]
Category: IMU, Accelerometer, Magnetometer & Gyroscope
Tags: Robotic Sensors, accelerator, Gyro, IMU, Inertial Measurement Unit, Robot Stabilizer, 6 DOF

The MPU-6050 3-Axis Accelerometer and Gyro Sensor module use MPU-6050 which is a little piece of motion processing tech. The MPU6050 datasheet is available in the attachment section to get this visit.

There are different types of magnetometer are available the basic differences between MPU6000, MPU6050 and MPU6500 is:

MPU6000 MPU6050 MPU6500
1. A sampling rate of 8 kHz. 1. A sampling rate of 8 kHz. 1. A sampling rate of 32 kHz.
2. Supports SPI and I2C interface. But I2C is too slow to handle 8 kHz gyro update. 2. Supports I2C interface communication protocol. 2. Supports both I2C and SPI interface.
3. Vibration Sensitivity is better than MPU6500. 3. Vibration Sensitivity is better than MPU6500 but the speed of operation is less than MPU6000. 3. It is more susceptible to vibrations, so the need for some vibration isolation methods.

It is faster than both MPU.

The MPU6050 devices combine a 3-axis gyroscope and a 3-axis accelerometer on the same silicon together with an onboard Digital Motion Processor (DMP) capable of processing complex 9-axis MotionFusion algorithms. To get more insights about specifications visit the MPU6050 datasheet.

If you want to Explore more about Accelerometer Then click on, Accelerometer and Gyroscope


Features :

  1. Chip built-in 16bit AD converter, 16-bit data output.
  2. I2C Digital-output of 6 or 9-axis MotionFusion data in rotation matrix, quaternion, Euler Angle, or raw data format.
  3. Selectable Solder Jumpers on CLK, FSYNC, and AD0.
  4. Digital Motion Processing™ (DMP™) engine offloads complex MotionFusion, sensor timing synchronization, and gesture detection.
  5. Embedded algorithms for run-time bias and compass calibration. No user intervention is required.
  6. Digital-output temperature sensor.

Package Includes:

1 x MPU-6050 Gyro Sensor 2 + Accelerometer.

1 x 1*8 Burg connector Pins(Right angle).

1x 1*8 Burg connector Pins(Straight).

Driver IC

MPU-6050

Operating Voltage (VDC)

3 ~ 5

Communication

I2C Protocol

Gyro range(°/s)

± 250, 500, 1000, 2000

Acceleration range(g)

± 2 ± 4 ± 8 ± 16

Length (mm):

20

Width (mm):

16

Shipping Weight 0.01 kg
Shipping Dimensions 3 × 2 × 1 cm
15 Days Warranty

This item is covered with a standard warranty of 15 days from the time of delivery against manufacturing defects only. This warranty is given for the benefit of Robu customers from any kind of manufacturing defects.  Reimbursement or replacement will be done against manufacturing defects.


What voids warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.

Based on 22 reviews

5.0 overall
22
0
0
0
0

Add a review

  1. Akshay (verified owner)

    Best quality
    After caliberation precision of sensor was great
    working as expected
    robu is unbeatable in pricing

    Akshay

  2. (verified owner)

    Good product received. Must have to solder the pins into the board. Works well for my proecf

  3. V N M (verified owner)

    Original arduino only. Just the figure looks a bit different.

    V N M

  4. EPHRAIM 8689

    Best quality for price

    EPHRAIM 8689

  5. EPHRAIM 8689

    Nice Product

    EPHRAIM 8689

  6. Harsh Sharma (verified owner)

    amazing quality

    Harsh Sharma

  7. nilyash81 (verified owner)

    MPU is best in the cost. Readings are accurate and reliable. Using for quads successfully.

    nilyash81

  8. piyushsuteri (verified owner)

    Good product

    piyushsuteri

  9. mihirfulari

    Works as expected and quality is excellent

    mihirfulari

  10. Amit Kumar (verified owner)

    nicely packed and the module is working fine, and fast delivery too

    Amit Kumar

  11. haunter.dope (verified owner)

    just perfect !!! works perfectly!!

    haunter.dope

  12. gokukgoks008 (verified owner)

    Good

    gokukgoks008

  13. rajatmo (verified owner)

    Works as expected but I have no idea how to calibrate the gyro without very sophisticated experiment setups.
    The delivery was super fast.

    rajatmo

  14. Akash Bag (verified owner)

    working very good. thank you robu.in a shall recomend others to buy it. I shall use it for making arduino drone

    Akash Bag

  15. iversions (verified owner)

    works as described and it is amazing. planned to use it with esp32. delivered on time.

    iversions

  16. [email protected] (verified owner)

    good quality, works very well, delivered really fast.

    [email protected]

  17. Akshay KG (verified owner)

    Good quality and easy to interface with arduino

    Akshay KG

  18. [email protected]

    very good

    [email protected]

  19. konu2705 (verified owner)

    sensor exactly the same as shown in the image is delivered ! very happy!

    konu2705

  20. SUJEET KUMAR YADAV

    Very good sensor. I have purchased this from ebay.in for my Arduino bassed light controller.

    SUJEET KUMAR YADAV

  21. fusion669 (verified owner)

    delivered to WB within 4 days!!!

    fusion669

  22. fusion669 (verified owner)

    as expected !!!!!
    delivered really fast!!

    fusion669

MPU6050 Datasheet

Questions and answers of the customers

  1. 0 votes
    Q Is calibration needed for this product before using? answer now
    Asked by ikbal.ahmed on October 23, 2023 12:23 pm
    A

    Yes calibration is needed.

    thank you for... Read more

  2. 0 votes
    Q Do we need to calibrate the accelerometer before using it? answer now
    Asked by ikbal.ahmed on October 22, 2023 6:05 pm
    A

    yes you can.

    thank you for asking your d... Read more

  3. 0 votes
    Q Will it come soldered? If not, can you all solder it? answer now
    Asked by medal.apoorav on September 21, 2021 9:32 am
    A

    No.

Only registered users are eligible to enter questions
Country Of Origin: China
