Refurbished – Orang High Torque DC Gear Motor 24V-200KG.1CM-180K

Availability:

Out of stock

Approx Restocking Date: 25 to 30 Days
SKU: 1775613
  1. Brand: Orange
  2. Voltage: 24V
  3. RPM: 15
  4. Gear Ratio: 180:1
  5. Low Noise
  6. Smooth Ruining
  7. Weight Lift: 200KG.1CM

 9,736.00

(Including GST)

Out of stock


Free Delivery above ₹499
Free Delivery
above ₹499
1 Year Warranty
6 Months Warranty
Cash On delivery
Cash on Delivery*

Didn’t find what you are looking for?

You must register to use the waitlist feature. Please login or create an account
Brand: Orange
Category: Refurbished, Refurbished Motors | Drivers | Pumps | Actuators

This is a Refurbished – Orang High Torque DC Gear Motor 24V-200KG.1CM-180K

Below is the link If you want a brand new https://robu.in/product/orang-high-torque-dc-gear-motor-24v-200kg-1cm-180k/

Condition : There is negligible scratch mark on the product body.

This is a Orang High Torque DC Gear Motor 24V-200KG.1CM-180K.

This is 24V DC high torque motor, like a donut and thus has a large diameter and short axis. These motors can directly drive the application without additional mechanics, like worm wheels, belts or pulleys This technology enhances productivity, accuracy, and dynamic performance of applications. Direct drive lowers costs, makes designs slimmer, and reduces wear and tear.

Torque motors eliminate the need for mechanical transmissions like gearboxes, belts and speed reducers A torque motor is a specialized form of DC electric motor which can operate indefinitely while stalled, without incurring damage. In this mode of operation, the motor will apply a steady torque to the load (hence the name). A torque motor that cannot perform a complete rotation is known as a limited angle torque motor

Applications:

  1. Parking Garage
  2. Conveyer Belt
  3. Food Machinery
  4. Printing Machinery
  5.  Vending machine
  6. Power tools
  7. Robotic
  8. Sliding gate
  9.  Agricultural machinery
  10.  Labeling machine
  11. Hand mixer
  12. Juice agitator

Features:

  1. Low Noise
  2. Smooth Ruining
  3. Torque: 5kg.cm-200kg.cm
  4. Strong Power
  5. Motor type: Brushed PMDC motor
  6. Carbon Brush on two side of Motor
  7. Customized Output Shaft meet your different requirements
  8. Tail Made for connecting to encoder
  9. Red & Black Leading wiring
  10. Screw holes help you to install easily with machinery

packages Includes:

1 x High Torque DC Gear Motor 24V-200KG.CM-180K

Brand

Orange

Product Name

Orang High Torque DC Gear Motor 24V

Motor Type

Gear Motor

Power

60W

Voltage

24V

Weight Lift

200KG.1CM

Current

12A

Construction

Permanent Magnet

Gear type(Gearbox)

GU: General Helical Gear; GN: Reinforced Helical Gear

Shaft Type

Parallel shaft

Gear ratio

180:1

RPM

15

Torque

205

Insulation resistance

In the circumstance of normal temperature and humidity,
the resistance can be up to 100MΩ,measured by DC 500V
insulation resistance measurer between the motor wiring
and motor shell while the motor is working

Length(cm)

23

Width(cm)

9

Height(cm)

9

Weight(kg)

3,172

Shipping Weight 3.271 kg
Shipping Dimensions 25 × 10 × 10 cm
6 Months Warranty

This item is covered with a supplier warranty of 6 months from the time of delivery against manufacturing defects only. This is a quality product from the original manufacturer. Only manufacturing defects are covered under this warranty. Replacement will be done against manufacturing defects.


What voids the warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.

Based on 0 reviews

0.0 overall
0
0
0
0
0

Be the first to review “Refurbished – Orang High Torque DC Gear Motor 24V-200KG.1CM-180K”

There are no reviews yet.

Datasheet

Questions and answers of the customers

There are no questions yet. Be the first to ask a question about this product.

Only registered users are eligible to enter questions
Country Of Origin: China
